BESVIEW 8MP Dual-Lens Gun-Ball Linkage PTZ Camera
Dual-Lens PoE PTZ Security Camera
Outdoor 8MP Gun-Ball Linkage PTZ Camera

8MP Dual-Lens Gun-Ball Linkage PoE PTZ Security Camera with 20X Optical Zoom

BC-IQ50YDW-8MQ
Key Features
8MP Dual-Lens Imaging - Combines two 4MP imaging units in one integrated security camera system.
Gun-Ball Linkage Design - Combines a fixed wide-angle camera with a PTZ camera for wide-area and detailed surveillance.
20X Optical Zoom - The PTZ camera uses a 4.7–94mm motorized lens for long-distance viewing.
Wide-Area Monitoring - The 2.8mm fixed lens provides a wide monitoring view.
360° PTZ Coverage - Supports 0–360° pan and -15° to 90° tilt for flexible surveillance coverage.
Human Detection - Supports AI-based human detection for targeted security monitoring.
120m IR Night Vision - Provides long-range infrared illumination for nighttime surveillance.
PoE Connectivity - Supports power and network transmission through a single Ethernet cable.
IP66 Protection - Designed for outdoor surveillance environments.
Two-Way Audio - Built-in microphone and speaker support audio communication.
256 Presets - Supports preset positioning and cruise functions.
MicroSD Storage - Supports microSD cards up to 256GB.
Contact Now
Download directory

Dual-Lens Gun-Ball Linkage PTZ Camera

The BESVIEW 8MP dual-lens gun-ball linkage PTZ camera combines two 4MP imaging units in one integrated camera system. The fixed camera provides wide-area monitoring, while the PTZ camera features 20X optical zoom for detailed long-distance surveillance. With 360° pan, -15° to 90° tilt, human detection, up to 120m IR illumination, PoE connectivity and IP66 protection, it is designed for professional outdoor surveillance applications.

Image Sensor:1/3'' Cmos Sensor+1/3'' Cmos Sensor
Signal System:PAL/NTSC
Min. Illumination:Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR
Shutter Time:1/25 s to 1/10,000 s
Lens:2.8mm Fixed lens+20X 4.7-94mm Motor Lens
Day&Night:IR cut filter with auto switch
Image Enhancement:BLC/3D DNR/D-WDR
Motion DetectionSupport
Intelligent Detection(AI)Human Detection
Privacy ProtectionSupport(4 Self-customized Areas)
Wather-Proof:IP66
Illumination for Infrared Switching:1~5Lux
Infrared Wavelength:850nm
Mimimum Illumination:0 Lux(IR ON)
IR Range:8PCS IR/2pcs white light //120m IR/40m white
Compression Standard
Video Compression:H.265/H.264
Video Bit Rate:512Kbps~6144Kbps(main stream H.265)
64kbps~512Kbps(sub stream H.265)
Audio Compression:G711U/G711A/AAC
Dual Streams:Yes
Triple Streams:No
Max. Image Resolution:2560*1440@30fps/1920*1080@30fps
Frame Rate:25fps(4MP).MAX main stream
30fps（D1) .MAX sub stream
Image Settings:3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness
adjustable via client software, web browser or Smartphone App
Day/Night Switch:EXT/Day/Night/Auto/Time
Audio
Line IN/line OUT：Support（1ch）
Build-in MIC/SPK：Yes
Volnume adject：Yes
Network
Network Protocols:HTTP, TCP/IP, IPv4/v6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,
DDNS,IP Search(Support P2P, NVR, NVS etc.)
System Compatibility:ONVIF 22.12 + Profile S / Profile T / Profile M
On-line ViewingMax. Support 2 Users Simultaneously
Interface
Communication Interface:1 RJ45 10M / 100M Ethernet Interface
SD card interfaceSupport TF card（micro TF card，up to 256G）
DC Power Plug:DC Power Femate Interface
PTZ
AnglePan:0~360° / Tilt:-15~90°
speedPan: about 30°/s / Tilt: about 30°/s
presetsupport 256 preset
General
Operating Conditions:-10 °C ~ 60 °C
Humidity 95% or less (non-condensing)
Power Supply:12 V DC ± 10%/PoE
Power Consumption:12 VDC ± 10%, Max Power Comsumption Less than 25W
 (When the infrared lamps turn on)
