8MP 4K PoE IP Camera with Dual-Light Night Vision, Human & Vehicle Detection

BC-IE253DW-8ME

8MP 4K High-Resolution Imaging Delivers images at up to 3840 × 2160 resolution, helping capture more visual detail for commercial and residential security monitoring.
Dual-Light Night Vision Combines infrared and warm-light illumination, with configurable night modes to suit different surveillance and lighting requirements.
Human and Vehicle Detection Helps distinguish relevant human and vehicle activity from general movement for more focused security monitoring.
IP66 Protection and Housing Options Designed for outdoor surveillance applications with IP66-rated protection. Metal housing can be discussed as a configuration option for projects requiring a different enclosure.
Flexible Network and Power Configuration Supports Ethernet network connectivity, with PoE available as an optional power configuration according to the product specification.
Optional Audio and Local Storage Two-way audio and microSD card storage can be specified according to the selected hardware configuration and project requirements.

Contact Now

Download directory

8MP 4K PoE IP Security Camera with Dual-Light Night Vision

The BESVIEW BC-IE253DW-8ME is an 8MP network security camera developed for commercial surveillance, building security and customized CCTV projects. Its 3840 × 2160 maximum resolution delivers detailed images for monitoring entrances, retail premises, offices, warehouses and other security-sensitive areas.

The camera combines infrared and warm-light illumination to support different night surveillance modes. Depending on the selected settings, it can use infrared illumination for discreet nighttime monitoring or activate warm light to provide color imaging in suitable low-light conditions.

Human and vehicle detection helps users focus on relevant movement, while H.265/H.264 video compression supports efficient video transmission and recording. The camera supports a fixed 3.6mm lens, IP66-rated protection and network connectivity. PoE, audio interfaces, microSD storage and metal housing configurations should be confirmed according to the selected version.

As a security camera manufacturer, BESVIEW supports OEM/ODM projects involving product configuration, housing options, logo printing, packaging and software or protocol customization, subject to technical evaluation.

Image Sensor:	1/2.7” High sensitivity CMOS
Signal System:	PAL/NTSC
Min. Illumination:	Color: 0.05lux @(F1.6, AGC ON), 0 lux with IR or light
Shutter Time:	1/25 s to 1/10,000 s
Lens:	3.6mm fixed lens
Day&Night:	2pcs Homologous Dual Light (Warm Light+IR LED Light)
Image Enhancement:	BLC/3D DNR
Motion Detection:	Support
Privacy Protection:	Support(4 Self-customized Areas)
Smart function:	Humanoid detection,Vehicle detection
Illumination for Infrared Switching:	0.5~3Lux
Infrared Wavelength:	850nm
Mimimum Illumination:	0 Lux(IR ON)
LED Light Distance	IR 25m/Warm light 20m
Wather-Proof:	IP66
Compression Standard
Video Compression:	H.265/H.264
Video Bit Rate:	512Kbps~6144Kbps(main stream H.265) 64kbps~1024Kbps(sub stream H.265)
Dual Streams:	Yes
Triple Streams:	No
Image Resolution:	main stream:38402160(8MP)/25961944(5MP) /2560*1440(4MP)/1920x1080(1080p) sub stream:720x480(D1)/640x480(VGA)/640x360/352x288(CIF)
Frame Rate:	main stream:20fps(8MP) max. sub stream:25fps max
Stream:	two streams
Image Settings:	3D NR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App
Day/Night mode	support Full color mode，auto switch mode（BW with IR led）,trigger mode(Humanoid triggers white light at night）
Audio
Audio Compression:	G711U/G711A/AAC
Audio Bitrate	64K(G711)/16k(AAC)
Audio In/Out：	Optional (RCA socket)
Build-in MIC：	Yes
Build-in speaker：	Yes
Volnume adject：	Yes
Network
Network Protocols:	Http/Https, TCP/IP, IPv4/v6, UPNP, RTSP/RTMP,FTP, UDP, SMTP, NTP, DHCP, DNS, DDNS,IP Search(Support P2P, NVR, NVS etc.)
General Function:	Anti-Flicker, heartbeat, password protection, privacy mask, Watermark
System Compatibility:	ONVIF(17.2 with profile S)
On-line Viewing	Max. Support 2 Users Simultaneously
Interface
Communication Interface:	1 RJ45 10M / 100M Ethernet Interface
Audio Interface:	RCA Audio input/output Interface (Optional)
Alarm in/out interface：	Support（1ch）（Optional）
SD card interface	Support TF card（micro TF card，up to 256G）
DC Power Plug:	DC Power Femate Interface/POE(optional)
General
Operating Conditions:	-10 °C ~ 60 °C
Operating Conditions:	Humidity 95% or less (non-condensing)
Power Supply:	12 V DC ± 10%/PoE(Optional)
Power Consumption:	12 VDC ± 10%, Max Power Comsumption Less than 8W (When the infrared lamps turn on)

IP Camera Compatibility with NVR and VMS Systems

BESVIEW IP cameras are designed for integration into a range of video surveillance systems. Depending on the model and firmware, supported protocols and interfaces may include ONVIF, RTSP and RTMP to facilitate integration with compatible third-party NVRs, VMS platforms and video management solutions.
ONVIF Profile Support
Selected models support ONVIF Profiles S, T and M, subject to the specific product specification and firmware version. These profiles cover different aspects of video streaming, device interoperability and supported metadata functions. Actual feature availability depends on the camera model and the receiving system.
Third-Party NVR and VMS Integration
Before deployment, buyers should verify the camera model, ONVIF profile, firmware version, video codec, resolution, audio requirements and required event functions against their existing NVR or VMS system.
OEM/ODM Integration Support
For projects requiring customized integration, BESVIEW can evaluate SDK/API access, protocol requirements and software customization based on technical feasibility and project scope.
Contact our team with your NVR/VMS brand and model to discuss compatibility testing and integration requirements.

BESVIEW Security Cameras Compatible with Third-Party NVR and VMS Systems

OEM/ODM Security Camera Manufacturer for Custom Projects

Shenzhen Besview Security Limited provides OEM/ODM security camera solutions for distributors, wholesalers, security brands, system integrators and project buyers. We support customization based on product requirements, target markets and order quantities.

• Product Branding: Custom logo printing and product identification options.
• Housing Customization: Evaluation of private housing designs, materials and mechanical requirements.
• Packaging Design: Customized color boxes, labels and product packaging.
• Software Customization: Evaluation of web interface branding, supported software functions and integration requirements.
• SDK/API and Protocol Support: Technical evaluation for third-party system integration and project-specific development.
• Project-Based Engineering Support: Assistance with product selection, sample evaluation and customization planning.

Contact BESVIEW to discuss your target specifications, estimated order quantity, destination market and customization requirements. Our team can evaluate technical feasibility, MOQ, sample availability, tooling costs and production lead time.

OEM ODM Security Camera Manufacturer Offering Hardware and Software Customization

Q1: What resolution does the BESVIEW BC-IE253DW-8ME support?

A: The camera supports a maximum resolution of 3840 × 2160 pixels (8MP) at up to 20 fps, according to the published specifications.

Q2: How does the dual-light night vision system work?

A: The camera combines infrared and warm-light illumination. Depending on the selected mode, it can use infrared for black-and-white nighttime imaging or warm light for color imaging when lighting conditions and settings support it.

Q3: Does this 8MP IP camera support human and vehicle detection?

A: Yes. The published specifications list human detection, vehicle detection and motion detection. Detection performance depends on installation and configuration.

Q4: Does the camera support PoE?

A: PoE is listed as an optional power configuration. Please confirm the required power version when ordering.

Q5: Is two-way audio available?

A: Audio configuration options are available for discussion, including optional audio input/output interfaces. Please confirm whether the selected version includes a microphone, speaker and the required audio functions.

Q6: Does the camera support a microSD card?

A: The current specification lists TF card storage up to 256GB. Please confirm the card slot and supported capacity for your selected hardware configuration.

Q7: Can the camera be supplied with a metal housing?

A: A metal housing can be discussed as an optional project configuration, subject to factory confirmation of mechanical design, availability and protection rating.

Q8: Is the camera compatible with third-party NVR and VMS systems?

A: The published specification lists ONVIF 17.2 Profile S and RTSP support, along with RTMP. Compatibility depends on the third-party system, firmware and required functions. Integration testing is recommended before deployment.

Q9: Does BESVIEW provide OEM and ODM services?

A: BESVIEW supports OEM/ODM project discussions covering product branding, housing options, packaging and software or protocol customization, subject to technical feasibility and order requirements.

Q10: How can I request a quotation or sample?

A: Contact BESVIEW with your target quantity, required hardware configuration, destination market and OEM/ODM requirements. The sales team can confirm sample availability, pricing, MOQ, lead time and shipping options.
