8MP 180 Degrees PoE IP Camera

BC-IE30KDW-8ME
Key Features
• 8MP 4K Resolution - Delivers up to 3840 × 2160 resolution at 20fps for detailed surveillance images.
• 180° Wide-Angle View - 1.7mm fixed lens provides a 180° horizontal viewing angle for wide-area coverage.
• Dual-Light Night Vision - Combines infrared and white-light illumination for day and night surveillance.
• PoE Connectivity - Supports PoE for simplified power and network installation.
• Human & Vehicle Detection - Supports intelligent detection for more targeted surveillance monitoring.
• Built-in Audio - Built-in microphone and speaker support two-way audio communication.
• IP66 Weatherproof Housing - Designed for outdoor security applications and challenging environments.
• ONVIF & RTSP Support - Enables integration with compatible NVR and VMS platforms.
• MicroSD Storage - Supports up to 256GB microSD/TF card storage.
• OEM & ODM Support - Available for customized housing, logo, hardware, software and packaging based on project requirements.
Contact Now
Download directory
Image Sensor:1/2.7'' CMOS
Signal System:PAL/NTSC
Min. Illumination:Color: 0.05lux @(F1.6, AGC ON), 0 lux with IR or light
Shutter Time:1/25 s to 1/10,000 s
Lens:1.7mm fixed lens
Day&Night:4pcs dual light
Image Enhancement:BLC/3D DNR/D-WDR
Motion Detection:Support
Privacy Protection:Support(4 Self-customized Areas)
Smart function:Humanoid detection,Vehicle detection
Illumination for Infrared Switching:0.5~3Lux
Infrared Wavelength:850nm
Mimimum Illumination:0 Lux(IR ON)
LED Light DistanceIR 25m/white light 15m
Wather-Proof:IP66
Compression Standard
Video Compression:H.265/H.264
Video Bit Rate:512Kbps~12288Kbps(main stream H.265)
64kbps~1024Kbps(sub stream H.265)
Dual Streams:Yes
Triple Streams:No
Image Resolution:main stream:3840*2160(8MP)/2592x1944(5MP)/2560x1440(4MP)/1920x1080(1080p)
sub stream:720x480(D1)/640x480(VGA)/640x360/352x288(CIF)
Frame Rate:main stream:20fps(8MP) max.
sub stream:25fps max
Stream:two streams
Image Settings:3D NR,WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness
adjustable via client software, web browser or Smartphone App
Audio
Audio Compression:G711U/G711A/AAC
Audio Bitrate64K(G711)/16k(AAC)
Build-in MIC/Speaker：Yes
Volnume adject：Yes
Network
Network Protocols:Http/Https, TCP/IP, IPv4/v6, UPNP, RTSP/RTMP,FTP, UDP, SMTP, NTP, DHCP, DNS,
DDNS,IP Search(Support P2P, NVR, NVS etc.)
General Function:Anti-Flicker, heartbeat, password protection, privacy mask, Watermark
System Compatibility:ONVIF(17.2 with profile S)
On-line ViewingMax. Support 2 Users Simultaneously
Interface
Communication Interface:1 RJ45 10M / 100M Ethernet Interface
SD card interfaceSupport TF card（micro TF card，up to 256G）
DC Power Plug:DC Power Femate Interface/POE
General
Operating Conditions:-10 °C ~ 60 °C
Humidity 95% or less (non-condensing)
Power Supply:12 V DC ± 10%/PoE
Power Consumption:12 VDC ± 10%, Max Power Comsumption Less than 8W
 (When the infrared lamps turn on)
Weight:0.56KG
