6MP 5X optical zoom IP turret security camera BC-IE33BRW-6M3

6MP 5X Optical Zoom IP Turret Security Camera with AI Detection

BC-IE33BRW-6M3
The Besview 6MP 5X optical zoom IP security camera features a 2.7–13.5mm motorized lens for flexible monitoring of entrances, parking areas, commercial buildings and other surveillance locations. With human and vehicle detection, infrared night vision, PoE power options and IP66 protection, it supports professional network surveillance deployments. OEM/ODM customization is available for qualified B2B projects.
Contact Now

6MP 5X Optical Zoom IP Turret Security Camera

Product Description · English copy

The Besview BC-IE33BRW-6M3 is a 6MP IP security camera designed for commercial and professional surveillance applications. Its 5X motorized 2.7–13.5mm lens provides flexible viewing adjustment, helping installers adapt the camera's field of view to different monitoring distances and scene requirements.

• 6MP High-Resolution Imaging - Supports a maximum resolution of 3072 × 2048 at 20fps for detailed surveillance footage.

• 5X Motorized Optical Zoom - Features a 2.7–13.5mm motorized lens for flexible monitoring of entrances, parking areas, building perimeters and commercial facilities.

• AI Human and Vehicle Detection - Supports human and vehicle detection to help users identify relevant activity in monitored areas.

• Infrared Night Vision - Uses infrared illumination and an automatic IR-cut filter to support day-and-night monitoring, including in low-light conditions.

• H.265/H.264 Video Compression - Supports H.265, H.264 and MJPEG video compression to accommodate different recording and network bandwidth requirements.

• PoE and DC Power Options - Supports PoE or 12V DC power, subject to the final hardware configuration, helping installers select a suitable power arrangement.

• IP66 Weather Protection - Designed for outdoor surveillance installations where protection against dust and water exposure is required.

• Network Monitoring and Remote Access - Supports RTSP, network access and P2P cloud functionality for compatible viewing and management applications.

• Flexible Installation and Integration - Supports connection to compatible network recording and management systems. Verify protocol profiles and third-party device compatibility before deployment.

• OEM/ODM Customization - Besview provides B2B security camera manufacturing services, with customization options subject to project requirements, hardware configuration and order quantity.


Image Sensor:1/2.7''Cmos Sensor
Signal System:PAL/NTSC
Min. Illumination:Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR
Shutter Time:1/25 s to 1/10,000 s
Lens:5X 2.7-13.5mm Motor Lens
Day&Night:IR cut filter with auto switch
Image Enhancement:BLC/3D DNR/D-WDR
Motion DetectionSupport
Intelligent Detection(AI)Human Detection,Vehicle detection
Privacy ProtectionSupport(4 Self-customized Areas)
Wather-Proof:IP66
Illumination for Infrared Switching:1~5Lux
Infrared Wavelength:850nm
Mimimum Illumination:0 Lux(IR ON)
IR Range:6pcs IR LED//25m IR
Compression Standard
Video Compression:H.265/H.264/MJPEG
Video Bit Rate:512Kbps~6144Kbps(main stream H.265)
64kbps~1024Kbps(sub stream H.265)
Audio Compression:G711U/G711A/AAC
Dual Streams:Yes
Triple Streams:No
Max. Image Resolution:3072*2048@20fps/2592*1944(5MP)@25fps/1920*1080(2MP)30fps
Frame Rate:20fps(6MP).MAX main stream
25fps(D1) .MAX sub stream
Image Settings:3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness
adjustable via client software, web browser or Smartphone App
Day/Night Switch:EXT/Day/Night/Auto/Time
Audio
Line IN/line OUT:Support(1ch)
Build-in MIC:Optional
Volnume adject:yes
Network
Network Protocols:HTTP, TCP/IP, IPv4/v6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,
DDNS,RTMP,IP Search(Support P2P, NVR, NVS etc.)
System Compatibility:ONVIF(17.2 with profile S/T/M)
On-line ViewingMax. Support 2 Users Simultaneously
Interface
Communication Interface:1 RJ45 10M / 100M Ethernet Interface
RCA Audio Interface:RCA Audio input/output  Interface (Optional)
Alarm in/out interface:Support(1ch) (Optional)
DC Power Plug:DC Power Femate Interface
General
Operating Conditions:-10 °C ~ 60 °C
Humidity 95% or less (non-condensing)
Power Supply:12 V DC ± 10%/PoE
Power Consumption:12 VDC ± 10%, Max Power Comsumption Less than 8W
 (When the infrared lamps turn on)
